ivy_thigmotropism II

This is just another attempt to improve the script and recreate the phenomenon of thigmotropism. In this case the organism grows in a surface even if there are some parameters that I still not control at all. I'm thinking of what this system can evolve and create forms and spaces even though in nature it's a parasite.

Option Explicit
'Giacomo Damiani
'Script version lunedì 16 marzo 2009 23.50.56

Call Main()
Sub Main()

Dim n,i,j,p, dblparam,dblparam2, dblradius,arrplane,strcurve,arrCirc2, strcurvecrv,arrcrvdata,arrCPlane,arrPlane3,ArrRPlane,Arrmoveplane,dblparam3,arrcurve

Dim strcrv: strcrv = Rhino.GetObject("select curve",4)
Dim strsrf: strsrf = Rhino.GetObject("select surface",8)

If isNull(strcrv) Then Exit Sub
If isNull(strsrf) Then Exit Sub

Dim IntNPt: intNPt = Rhino.GetInteger("how many frame?", 60, 10, 80)
Call Rhino.EnableRedraw(False)

Dim arrDom3: arrDom3 = Rhino.CurveDomain(strCrv)

Dim dblstep3: dblStep3 = (arrDom3(1)-arrDom3(0))/(intNPt+1)
ReDim arrplane3(intNpt-1)
ReDim dblparam3(intNpt-1)

For p=0 To intNpt-1

dblParam3(p) = arrDom3(0) + p*dblStep3
arrPlane3(p) = Rhino.CurvePerpFrame(strcrv, dblParam3(p))
'i take a curve and the section is make in planes create by this curve

arrcurve = Rhino.AddSrfSectionCrvs(strsrf,arrPlane3(p))
'section to the surface

If isNull (arrCurve) Then Exit Sub

Dim IntNPts: intNPts = Rhino.GetInteger("how many samples?", 100, 10, 200) 'chiedo il dimensionamento

If isNull (intNpts) Then Exit Sub

ReDim arrCirc(intNpts-1)
ReDim arrCirc2(intNpts-1)

Dim arrpt,strpt,arrpt2,arrpte,strpt2, strcurve1,arrplane2,dblradius2
ReDim arrcurve1(intNpts-1)
ReDim arrpt2(intNpts-1)
ReDim arrpte(intNpts-1)
ReDim arrpt(intNpts-1)
ReDim arrplane(intNpts-1)

For n=0 To ubound (arrcurve)

Dim arrDom: arrDom = Rhino.CurveDomain(arrCurve(n))
Dim dblstep: dblStep = (arrDom(1)-arrDom(0))/intNPts

For i=0 To intNpts-1

dblParam = arrDom(0) + i*dblStep
arrPlane(i) = Rhino.CurvePerpFrame(arrCurve(n), dblParam)

dblRadius = 0.09

arrCrvData = Rhino.CurveCurvature (arrCurve(n), dblParam)

arrCirc(i) = Rhino.AddCircle(arrPlane(i),dblRadius)

arrpt(i) = Rhino.EvaluateCurve(arrCurve(n),dblParam)

strpt = Rhino.AddPoint(arrpt(i))
arrpte(i) = Rhino.EvaluateCurve(arrcirc(i),dblparam*i)
arrpt2(i) = Rhino.MoveObject(strpt,arrpt(i),arrpte(i))
'arrCrvData = Rhino.CurveCurvature (strCurve, dblParam)


strcurve = Rhino.AddInterpCurve(arrpte)
Dim arrDom2: arrDom2 = Rhino.CurveDomain(strcurve)
Dim dblstep2: dblStep2 = (arrDom2(1)-arrDom2(0))/intNPts

For j=0 To ubound (arrpte)

dblParam2 = arrDom2(0) + j*dblStep2

arrPlane2 = Rhino.CurvePerpFrame(strcurve,dblparam2)
dblradius2 = 3/(j+6)

arrcirc2(j) = Rhino.AddCircle(arrplane2,dblradius2)

'Call Rhino.AddLoftSrf(arrCirc)
Call Rhino.AddLoftSrf(arrCirc2)


'Call Rhino.ObjectColor(arrCirc(i),RGB(0,0,255))


Call Rhino.EnableRedraw(True)
Call Rhino.HideObject(strsrf)

End Sub
